Smart IP Conferencing Camera

Smart IP Cam PTZ Pro 2

The Smart IP CAM-PTZ Pro 2 Conference Camera delivers Full HD 1080p video for professional meetings, video conferencing, and business presentations. Featuring 10x optical zoom, smooth pan-tilt-zoom (PTZ) control, and USB, HDMI, and 3G-SDI outputs, it is ideal for medium-sized conference rooms and corporate environments.

    Features
  • Sleek and intelligent design
  • Plug & Play USB Connectivity
  • Wide field of view with no video distortion
  • Superior quality with Full Glass Lens Material
  • 1/2.9″ high quality, 2.38MP (16:9) CMOS sensor
  • Support HD 1080P60/50/30/25, 1080i60/50,720P60/50,etc

Smart IP Conferecning Camera in Pakistan - Smart IP Cam PTZ Pro 2

The Smart IP CAM-PTZ Pro 2 Conference Camera is designed to enhance professional video conferencing with clear Full HD video and flexible camera control. Equipped with a 2.38-megapixel CMOS sensor and 10x optical zoom, it captures detailed visuals for meetings, presentations, and collaborative discussions. Its smooth, quiet pan-tilt-zoom functionality allows users to adjust viewing angles and focus on different participants. The camera supports simultaneous USB 2.0, HDMI, and 3G-SDI video outputs, providing flexibility for various conferencing setups. With multiple preset positions, low-light image processing, and support for ceiling, wall, and tripod mounting, the Smart IP CAM-PTZ Pro 2 is a practical solution for medium-sized meeting rooms and professional communication environments.

Specifications

View Datasheet

Image Sensor
1/2.9" CMOS
Effective Pixels
2.38 Megapixels (16:9)
Horizontal Resolution
1080P 60/50/30/25, 1080i 60/50, 720P 60/50
Focal Length
F = 5.0 mm (Wide) – 50.0 mm (Tele)
Zoom
10x Optical Zoom
Horizontal View Angle
51.8° (Wide) – 5.86° (Tele)
Pan / Tilt Range
Pan: 340° (Maximum Speed 80°/s), Tilt: 120° (Maximum Speed 60°/s)
Video Output
USB, HD-SDI, HDMI
Noise Reduction
2D / 3D
Signal Standard
NTSC / PAL
Gain Control
Auto / Manual
Signal-to-Noise Ratio (SNR)
1/30s – 1/10,000s, Auto (as specified in the datasheet)
Preset Positions
Remote Control: 9 Presets; PELCO Control Protocol: 255 Presets
Control Terminal
RS-232, RS-485
Control Protocol
VISCA, PELCO-D, PELCO-P (RS-232, RS-485)
Operating Temperature
-10°C to 50°C
Operating Humidity
-20° to 60° (as specified in the datasheet)
Baud Rate
34800 / 9600 bps
Address Set
1–64
Weight
1.7 kg / 3.5 kg (as listed in the datasheet)
Decoder
Built-in
Power Consumption
12W
Installation
Desktop, Tripod, Wall Mount, Ceiling Mount
Accessories
DC 12V Power Adapter, IR Remote Control, Ceiling Brackets and Screws, Manual, USB Cable
Dimensions (HxWxD)
260 × 175 × 180 mm (Camera); 296 × 225 × 223 mm (Packaging)
